Programmable Street Light Constant Current LED Driver

Programmable Street Light Constant Current LED Driver

    Payment Type: L/C,T/T
    Terms of Trade: FOB
    Delivery Time: 1-45 Days
    Packaging: 10pcs/CTN
    Productivity: 300,000pcs/month
    Brand: MOSO
    Transportation: Ocean,Land,Air,railway
    Place of Origin: China
    Supply Ability: 300,000pcs/month
    Certificate: CE,UL,ENEC,SAA,BIS,KC,etc.
    HS Code: 8504
    Port: Shenzhen,Guangzhou,Hongkong

Basic Info

Model No.: LDP-150M054

Product Description

Street Light LED Driver

LDP-150M054 street light led driver provides built-in timer dimming schedules further increasing the energy savings and CO2 reductions achieved with LED lighting. Monitored by an infrared based programming device, the fully programmed Constant Current LED Driver offer all dimming options and a wide range of output current in a single outdoor led driver, which deliver maximum flexibility with customized operating settings and intelligent control options for OEMs, as one outdoor led driver can be programmed for many different luminaire designs.


150W Outdoor Programmable Led Driverstreet light-1

Programmer by software

Programmer Software Interface

IR Controller


Product Features:


Use MCU control to limit the delivered power, output current configurable, output voltage self-reacting;
Built-in 3-in-1 dimming and auto-react:0-10Vdc, PWM signal, timer control;
Signal amplitude can be 5V or 10V;
Equipped with interactive visual software to customize output setting;
Universal input voltage: (90 ~ 305)Vac;

Soft-switching patented technology, high efficiency up to 93%;

Overall protection: Short circuit / Over temperature / Over voltage;
Surge immunity: DM-5KV, CM-10KV;
IP67, glue potted, suitable for dry / wet / damp locations;
Complied with CCC/CE/CB/ENEC/SAA/BIS/UL safety regulations.
Ambient temperature: -40℃ ~ +60℃.


Application:
LED street / tunnel lighting, industrial lighting, flood lighting, grow lights, etc.

Technical Paremeters:

Input Voltage

90~305 Vac

Protection

Functions

Short Circuit

Input Current

2.0A

Over Voltage

Inrush Current

75A

Over Temperature

Power Factor

0.96

Intelligent Control

Iout programmable

THD

≤15%

1~10V dimming

Operating Temp.

-40°C ~ 60°C

PWM dimming

IP Rating

IP67

Timer step dimming



Specification:

Model

Max Power

Vout Range

Iout Range

Default Spec.

Dimmable

Efficiency

(W)

(Vdc)

(A)

LDP-150M054

150W

20~54Vdc

0.42~4.20A

36Vdc 4.2A

Yes

90%

LDP-150M120

150W

60~120Vdc

0.21~2.10A

107Vdc 1.4A

Yes

91%

LDP-150M214-A

150W

80~160Vdc

0.11~1.10A

143Vdc 0.7A

Yes

91%

LDP-150M214-B

150W

140~214Vdc

0.09~0.94A

214Vdc 1.05A

Yes

91%

LDP-150M335

150W

176~335Vdc

0.07~0.70A

214Vdc 0.7A

Yes

92%

LDP-150R054

150W

20~54Vdc

0.42~4.20A

36Vdc 4.2A

No

90%

LDP-150R120

150W

60~120Vdc

0.21~2.10A

107Vdc 1.4A

No

91%

LDP-150R214-A

150W

80~160Vdc

0.11~1.10A

143Vdc 0.7A

No

91%

LDP-150R214-B

150W

140~214Vdc

0.09~0.94A

214Vdc 1.05A

No

91%

LDP-150R335

150W

176~335Vdc

0.07~0.70A

214Vdc 0.7A

No

92%
